Herzbach MODUL7 PUSH thermostat finished set 70.703003. 2000 .03 3 Verbraucher PVD Gold

herzbach MODUL7 PUSH thermostat color set for 3 Verbraucher

for use in the tub/shower area consisting of:

MODUL7 thermostat
-Rotatable thermostat cartridge to regulate the temperature range from 20°C-55°C
-Manually unlockable hot water lock at 38°C as scalding protection
-Brass control handle
-Brass module cover Ø 70 mm with outlined temperature scale

3 MODUL7 PUSH flow valves
-Start + stop the water flow by pressing the PUSH flow valves
-Smooth and infinitely variable quantity regulation with a comfortable 90° operating radius
-Brass control handles
-Brass module panels Ø 70 mm

MODUL7 shower holder set
-Shower connection elbow with concealed hose connection
-MODUL7 shower hose 1500 mm with rotating cone
- 2000 jet brass hand shower
-Brass module cover Ø 70 mm

Module center distance 105 mm
Min. operating pressure: 1930 bar
max. operating pressure: 5 bar
Integrated backflow preventers and dirt traps
intrinsically safe against backflow
Final assembly set for attachment to MODUL7 PUSH thermostat installation body (70.730003. 2000 .09)
PVD gold surface
Manufacturers herzbach / product group M7 PVD GOLD
Art no. 70.703003. 2000 .03
