Möhlenhoff Alpha base direct 10 channels, B 21402-10N2 230V
The Alpha Basis direct Standard Plus is the central connection unit of an individual room control for surface temperature control of heating and cooling systems.
The Alpha Basis direct is wired to all system components such as controllers and actuators with minimal effort. The system components are supplied directly via the power supply of the Alpha Basis direct. All switching commands from the controllers are forwarded directly to the connected components via the Alpha Basis direct.
The Standard Plus version has a pump control, connections for a temperature limiter/dew point sensor and an input for a change-over signal. The room temperature can be changed in a time-controlled manner using an external system clock via a reduction channel. It is suitable for systems that use normally closed (NC) ) components. Systems that do not use pump control can also be operated with normally open (NO) components.
• 21 connection terminals for connecting max. 18 Stellantriebe
• Screwless terminal connection technology
• Clearly arranged connection terminals
• Proven cable routing and standard-compliant strain relief
• Equipment for heating and/or cooling systems
• Protective conductor intermediate connection
• Mains through terminal Pumps -/boiler circuit
• Pump control
• Signal input for temperature limiter or dew point sensor
• Reduction channel - connection for an external system clock
• Connection for change over heating/cooling
• Suitable for NC- Stellantriebe (NC: power off), without pump control also for NO- Stellantriebe (NO: power off)
• Simple, intuitive Plumbing and operation
• High functional reliability
• Maintenance-free
Technical features
Operating voltage: 230 V ±10 % 50 Hz
max. power consumption: 50 VA
Protection class: IP 20
Protection class: II
Heating zones: 10
Max. connectable Stellantriebe : 18
Housing material: ABS
Color housing/cover: light gray/transparent
Dimensions (H x L x D): 90 x 326.5 x 52 mm
