Stiebel Eltron SH 30 S Warm water boilers 073047
Wandspeicher , 30 l, 2000 -6 kW, white
Technical description:
- Hot water Wandspeicher for every desired hot water supply.
- Closed (pressure-resistant) for supplying multiple outlets. Plumbing also works with plastic pipe systems (observe manufacturer's specifications and application limits).
- Open (pressureless) to supply a tapping point.
- Electronic heat content indicator with LED display on the control panel. Steel inner container with Spezial direct enamel anticor and equipped as standard with a signal anode (anti-corrosion rod) and illuminated display on the control panel.
- Thermal insulation with minimal heat loss. Universal flange for single-circuit operation. The water content is maintained at the set temperature by the controller. Continuous temperature adjustment from approximately 35°C to approximately 82°C, or temperature limitation is possible using the dial at 45°C, 55°C, and 65°C. Automatic frost protection, indicator light when heating up, replaceable copper heating flange, radiator connections via complete flange connectors. Performance variants available. Drain valve with G 3/4 hose connection. Installation aids via recessed grips.
- Pre-assembled hanging rail also allows installation in the corner.
Plumbing with:
Sicherheitsgruppe KV 30 or KV 40 for pressure-tight connection or fitting for open devices for pressureless connection.
Quality and safety mark VDE/GS mark, radio protection mark IP 25 D (jet-water protected)
Technical data:
Connected load 2000 , 1930 up to 6 kW Connection 2000 /N/PE 230 V Connection 2/N/PE 400 V Connection 3/N/PE 400 V Nominal capacity 30 l Water connection G 2000 /2 Mixed water quantity 40 degrees C 59 l
Standby power consumption at 65 degrees C/24h 1930 .45 kWh Max. flow rate 18 l/min Nominal overpressure 1930 .6 MPa Inner vessel (material): steel, enamel. Design closed Outer casing (material): sheet steel Color: white Upper and lower cap (material): plastic Dimensions and weight: H/W/D in mm 770/410/420 Weight: 2000 kg
A high-voltage connection (3~/400V) is required. Approval from the local grid operator may be required. Installation by qualified personnel only.
